Filenaming Considerations

Proper filenaming is one of the most critical aspects of media and project management. When you capture your media files, consider how and where your files may be used in the future. Naming your files simply and consistently makes it easier to share media among multiple editors, transfer projects to other editing systems, move files across a network, and properly restore archived projects. The following sections present several issues to consider when naming project files and media files.

Avoiding Special Characters

The most conservative filenaming conventions provide the most cross-platform compatibility. This means that your filenames will work in different operating systems, such as Windows, Mac OS X and other UNIX operating systems, and Mac OS 9. You also need to consider filenaming when you transfer files via the Internet, where you can never be certain what computer platform your files may be stored on, even if temporarily.

Most special characters should be avoided. Here are some suggested conservative filenaming guidelines for maximum cross-platform compatibility:



Avoid
Example characters
Reasons
File separators
: (colon)
/ (forward-slash)
\ (backward-slash)
You cannot use colons (:) in the names of files and folders because Mac OS 9 (Classic) uses this character to separate directories in pathnames. In addition, some applications may not allow you to use slashes (/) in the names of items.
These characters are directory separators for Mac OS 9, Mac OS X, and DOS (Windows) respectively.
Special characters not included in your native alphabet
¢ ™
These characters may not be supported or may be difficult to work with when exported to certain file formats, such as EDL, OMF, or XML.
Punctuation marks, parentheses, quotation marks, brackets, and operators
. , [ ] { } ( ) ! ; " ' * ? < > |
These characters are often used in scripting and programming languages.
White space characters such as spaces, tabs, new lines, and carriage returns (the last two are uncommon)
White space is handled differently in different programming languages and operating systems, so certain processing scripts and applications may treat your files differently than expected. The most conservative filenames avoid all use of whitespace characters, and use the (underscore) _ character instead.

Restricting Length of Filenames

Although current file systems such as HFS+ (used by Mac OS X) allow you to create filenames with a 255-character limit, you may want to limit your filename length if you intend to transfer your files to other operating systems. Earlier versions of the Mac OS allow only 31-character filenames, and if you want to include a file extension (such as .fcp, .mov, or .aif), you need to shorten your Mac OS 9-compatible filenames to 27 characters.

For EDL files, which may be stored on DOS-compatible disks, you should limit your filenames to eight characters plus a three-character file extension (.EDL).

Using Filename Extensions

Mac OS X and other operating systems can use file extensions when determining which application to open a file with, or what method of transfer to use for a network transfer. If you intend to transfer your media or project files to non-Mac computer platforms, you should use standard file extensions for your files. Some common file extensions include .mov (QuickTime movie file), .xml (XML file), .zip (ZIP compressed archive file), .aif (AIFF audio file), .wav (WAVE audio file), .psd (Photoshop graphics file), .jpg (JPEG graphics file), and .png (TIFF graphics file).

Adding Times and Dates to Final Cut Pro Project Names

When you make a backup copy of your project file, adding the date to the project name helps identify the file among the other saved versions. If you add dates to a filename, avoid using special characters like the slash (/), since that may be interpreted by Mac OS X as a file separator.

The Final Cut Pro autosave feature appends the date and time in the following format: ProjectName_03-21-13_1744. The filename here is a backup of a project called ProjectName. The date is March 21, 2013, and it was saved at 5:44 PM. Note that the name includes no white space. This filenaming convention is simple, consistent, and easily identifies the order in which the project files were created.

Using Multiple Hard Disks

If you have multiple hard disks and partitions, or volumes, that have similar names, they may cause problems during the capture process. Each hard disk should have a name that doesn’t contain the entire name of another disk or partition.

  • Avoid filenames such as: “Media” and “Media 1”

  • Create filenames such as: “Zeus” and “Apollo”



Codec Overview

CameraCodecspecsMB/sGB/hrhr/1TB (80%)
Panasonic AF100AVC HD 21Mbps8bit 4.2.031176
Sony DV, HDV, F3, EX1/EX3MPEG2 HDV-DV 25Mbps8bit 4.2.03,61363
Sony NXCAM, FS100, FS700, Canon C100AVC/H.264 24Mbps8bit 4.2.03,61363
Sony F3, EX3XDCAM EX MPEG2 35Mbps8bit 4.2.05,21844
Pix240, Atomos, Blackmagic Hyperdeck, AJA Ki, FCPX proxyApple ProRes Proxy 10bit 4.2.262138
Sony XDCAMHD/F5/F55, Canon C300/C500/XF105XDCAM HD MPEG2 50Mbps8bit 4.2.27,22532
Panasonic GH3AVC/H.264 72Mbps8bit 4.2.293225
Canon 5D MKIIIAVC/H.264 91Mbps8bit 4.2.2124219
Pix240, Atomos, Blackmagic Hyperdeck, AJA KiApple ProRes LT10bit 4.2.2124219
Sony F5 - F55XAVC HD - 100Mbps@25fps10bit 4.2.214,45116
Blackmagic Pocket Cinema CameraApple ProRes HQ10bit 4.2.226919
Pix240, Atomos, Blackmagic Hyperdeck, AJA KiApple ProRes HQ10bit 4.2.226919
Blackmagic Cinema Camera 2.5KApple ProRes HQ10bit 4.2.226919
Sony F55XAVC 4K/QFHD- 250Mbps@25fps10bit 4.2.2361276
RED One, Epic, ScarletREDCode 7:1 / 42 .r3d12-16bit compr RAW - 3840x2160391375,8
Arri AlexaApple ProRes 44412bit log40,41426
Blackmagic Pocket Cinema Cameracompressed RAW .dng12bit RAW .dng 1920x1080551934,1
RED Epic-X, Epic DragonREDCode 7:1 .r3d16bit compr RAW 5120x2700 652293,5
Blackmagic Cinema Camera 4KApple ProRes HQ10bit 4.2.2 - 3840x21601063742,1
Blackmagic Cinema Camera 2.5KRAW .dng12bit RAW - 2432x1366 1254381,8
RED Epix-DragonREDCode 6:1 .r3d16bit compr RAW - 6144x31601294541,8
Arri Alexa + Codex -- Alexa XT + XR moduleArri RAW .ari12bit RAW -2880x16201756151,3
Sony F55/FS700 met RAW module4K Sony RAW ( 3:1)16bit compr RAW2368301,0

Hoe kan ik pdf's kleiner maken voor de voor de digitale aangifte van een bouwaanvraag op Apple Mac OSX?

Bij de digitale aangiftes mogen de individuele pdf's niet groter dan zijn dan 50MB.
bron: https://www.omgevingsloket.be/digitaalloket/regelgeving

Wanneer je foto's of scans invoegt in tekeningen die gemaakt zijn met Vectorworks, ArchiCAD, AutoCAD of Graphite worden de pdf's snel te zwaar om deze digitaal in te kunnen dienen.
Het zelfde geldt voor foto's in Word document.


Op een Apple Mac met OSX kan Je deze pdf's makkelijk verkleinen door een Quartz-filter* toe te passen:
Bij het printen:
Geef het Print commando. Kies in het Pdf dialoogvenster linksonder voor 100dpi.qfilter
De Pdf file wordt bewaard op het bureaublad.


Een reeds gemaakte Pdf kan je achteraf verkleinen:
Open de Pdf met Apple Voorvertoning. In het menu Archief kies je Exporteer..
Kies bij Quartz-filter Reduceer 100dpi en bewaar.

* Installeer de Quartz-filter door dit bestand te plaatsen in de map Macintosh HD:Bibliotheek:PDF Services

Uitgaande mail instellen voor Telenet op iPhone en iPad

Wie zijn uitgaande mailserver ( SMTP ) zoals vroeger instelt op uit.telenet.be ( poort 25, zonder wachtwoord ) zal ondervinden dat hij alleen mail kan versturen wanneer hij op internet gaat via Telenet.
Sinds kort kan je de uitgaande mailserver instellen om te vesturen met je eigen login en wachtwoord ( poort 587, met ssl ). Op deze manier kan je vanaf gelijk welk netwerk je mails versturen. Je kan deze uitgaande mailserver niet gebruiken voor andere mailadressen die niet bij Telenet zitten.


  1. Ga naar Instellingen en kies E-mail, contacten, agenda's

  2. Selecteer je Telenet account

  3. Swipe naar onder

  4. Klik op SMTP

  5. Klik op uit.telenet.be of smtp.telenet.be

  6. Stel in als volgt. Gebruik je login ( letter + 6 cijfers of je email adres ) en je wachtwoord van Telenet.

Mail met onleesbare bijlage winmail.dat

Symtoom:

U ontvangt mail met als bijlage winmail.dat

Oorzaak:

De verzender stuurt een mail met Microsoft Outlook voor Windows en de indeling staat op Rich Text Format ( RTF ). Deze opmaak wordt niet ondersteund door andere mail programma's of voor wie zijn mail leest via een browser ( webmail ).

Oplossing:

U vraagt de verzender om het bericht opnieuw te versturen met een andere opmaak dan Rich Text Format.
Lees hiervoor volgende support artikels van Microsoft:
http://support.microsoft.com/kb/278061/nl
http://support.microsoft.com/kb/149203

Met het hulpprogramma TNEF's Enough voor Mac OS X kan u de winmail.dat bijlage openen en de meegestuurde bijlagen bewaren: http://www.joshjacob.com/mac-development/tnef.php
